Highlights:
- High cost performance, low budget user choice
- Small size, simple and stylish appearance
- High quality hardware bracket to effectively protect machine stability and life
- Easy loading paper structure, paper output design, humanized everywhere
- Support download and print LOGO trademark
- 160mm/s printing speed, maximum 80mm paper roll outer diameter
- Support USB, network port, USB+ Bluetooth
Specifications:
| Printing method | Direct line thermal | |
| Print width | 72mm paper width | |
| Point density | 576 points / line or 512 points / line | |
| Printing speed | 200 mm / sec | |
| Interface Type | USB+ network port, 9P serial port + USB, USB + Bluetooth (optional) | |
| Printer paper | 79.5 ± 0.5 mm × φ 80 mm | |
| Line spacing | 3.75 mm (can adjust the line spacing with commands) | |
| Number of columns | 80mm paper: Font A - 42 columns or 48 columns / Font B - 56 columns or 64 columns / Simple, Traditional - 21 columns or 24 columns | |
| Character size | ANK character, Font A: 1.5 × 3.0mm (12 × 24 points) Font B: 1.1 × 2.1mm (9 × 17 points) Jane / Traditional: 3.0 × 3.0mm (24 × 24 points) | |
| Bar code character | Extended character table | PC347 (Standard Europe), Katakana, PC850 (Multilingual), PC860 (Portuguese), PC863 (Canadian-French), PC865 (Nordic), West Europe, Greek, Hebrew, East Europe, Iran, WPC1252, PC866 (Cyrillic#2) , PC852 (Latin2), PC858, IranII, Latvian, Arabic, PT151 (1251) |
| Barcode type | UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/ CODE39/ITF/CODABAR/CODE93/CODE128 | |
| Buffer | Input buffer | 64k bytes |
| NV Flash | 256k bytes | |
| Power supply | Power Adapter | Input: AC 100-240V, 50~60Hz |
| Power supply | Output: DC 24V/2.5A | |
| Cash box output | DC 24V/1A | |
| Physical characteristics | Weight | 1.03 kg |
| Physical dimension | 190 × 140 × 131 mm (deep × width × height) | |
| Environmental requirements | Working environment | Temperature: 0～45°C, Humidity: 10～80% |
| Storage environment | Temperature: -10～60°C, Humidity: 10～90% (no condensation) | |
| Life | Cutter life | 1 million times |
| Print head life | 100 km |
Warranty:
3 Months
