DINTEK PowerMAX500TM unshielded Cat.6 / Class E U/UTP LSZH cable is guaranteed to exceed Cat.6 specifications as set down in ANSI/TIA and ISO/IEC standards. Our PowerMAX500TM solution comprises unshielded Cat.6 component compliant patch panels, keystones, and patch cords.
When combined with DINTEK’s unshielded Cat.6 / Class E U/UTP LSZH cable, an end-to-end channel exists that maximizes data throughput and provides headroom for future technologies operating to, and beyond Gigabit Ethernet.
Features:
Capable of handling the latest versions of Power over Ethernet
Conductor sizes for PowerMAX500TM Cat.6 set at 23AWG
LSZH jacketed 4 pair telecommunications cable
Successful transmission at 500Mhz up to a length of 70Mtrs
EZI-Pull 305Mtr Box for trouble free installation
Applications:
Horizontal and backbone cable
1000BASE-TX Gigabit Ethernet / 1000BASE-T Gigabit Ethernet
100BASE-TX Fast Ethernet / 10BASE-TX Ethernet
100 Mbps TP-PMD / 100VG-AnyLAN
Broadband Video / Voice / T1 / ISDN
10Gbit (500Mhz) Transmission up to length of 70Mtrs
Standards Compliance:
Performance - ANSI/TIA 568.2-D Cat.6 / ISO/IEC 11801
Structural - EN 13501-6:2014 | IEC 61156-5 | EN 50288-6-1
PoE capability - IEEE 802.3bt level 3 & 4 (PoE++ & 4PPoE)
Environmental - Conforms to RoHS and REACH Directives
Flame testing - EN 60332-1-2 | EN61034-2 | EN 60754-1/2
Independent Certification:
ETL Certification according to ANSI / TIA-568.2-D Cat.6
CPR Reaction To Fire Classification - Dca,s2,d2,a1 as per EN 50399
